Stainless Steel
Rod Ends
POS / PHS / SA / SI Series |304 / 316 / 420 / 440C Options
Corrosion Resistant: Ideal for washdown, marine & salt spray.
Multi-Series: POS / PHS / SA / SI for all load types.
Material Choice: 304/316 for corrosion, 420/440C for hardness.
Customizable: Special threads, tolerances & fits available.
Precision Engineered
For the most demanding environments
Select Your Series
Choose the structural configuration that matches your application requirements.
POS Series
General linkage & oscillating tasks. Corrosion resistant & stable fit.
- Wide size range
- Stainless steel body
- Match with locking hardware
PHS Series
Higher loads or harsher connection applications.
- High structural strength
- Harder material options
- Frequent motion ready
SA Series
Lightweight / compact linkage systems.
- Compact design
- Easy installation
- Space-constrained areas
SI Series
Long life & smooth movement requirements.
- Low friction options
- Continuous operation
- Flexible maintenance
RFQ Preparation Checklist
Required
- Series (POS / PHS / SA / SI)
- Thread (Male/Female, Metric/UNF, RH/LH)
- Size / Model or Key Dims (d, L)
Recommended
- Environment (Food / Marine / Outdoor)
- Load / Frequency (Approximate range)
- Preferred Material (304/316/420/440C)
Optional
- Maintenance Free?
- Sealed?
- Misalignment Spacers?
No Part Number?
Don't worry if you don't have a specific model number. Send us a photo of your application, structure dimensions, or sample parameters.
POS Series
POS series is designed for general linkage connections, oscillating tasks, and angle compensation structures. Suitable for environments requiring high corrosion resistance and stable fits.
Key Advantages
- Adaptable to various mounting structures, wide application range.
- Available in 304/316 for enhanced corrosion resistance.
- Ideal for pairing with jam nuts and locking washers.
PHS Series
Designed for higher load capacities and harsher operating conditions. PHS series offers structural robustness for critical industrial applications.
Key Advantages
- Stronger structural integrity for heavy duty tasks.
- Higher hardness material options available.
- Engineered for frequent motion cycles.
SA Series
The SA series focuses on lightweight and compact structural requirements, making it perfect for space-constrained linkage systems.
Key Advantages
- Compact design saves valuable installation space.
- Easy installation and replacement.
- Optimized for precision equipment.
SI Series
Engineered for stable lifespan and smoother movement performance. The SI series is the choice for continuous operation requirements.
Key Advantages
- Low friction options for smoother operation.
- Designed for continuous, high-cycle work.
- Flexible maintenance strategies (Lubricated or PTFE).
Material Options
Select the right grade for your specific environmental and mechanical requirements.
304 Stainless Steel
General Corrosion / Cost-Effective
General wet environments, standard food equipment zones.
For heavy salt spray or long-term marine use, upgrade to 316.
316 Stainless Steel
Marine Grade / Superior Corrosion
Seaside, salt spray, chemical media, frequent washdowns.
If higher hardness/wear resistance is needed, consider 440C.
420 Stainless Steel
Heat Treatable / Higher Hardness
Moving parts requiring higher wear resistance and strength.
Corrosion resistance is lower than 316; evaluate based on environment.
440C Stainless Steel
High Hardness / Maximum Wear
High wear / High strength linkage requirements.
Corrosion resistance differs from 316; prioritize based on wear vs corrosion.
Technical Specifications
Thread Options
- TypeMale / Female
- StandardMetric / UNF
- DirectionRH / LH (Optional)
Key Dimensions
- Bore (d)5mm - 50mm+
- Thread (d1)M5 - M48+
- Misalignment±5° to ±20°
Performance
- Static LoadUp to 100kN+
- Temp Range-50°C to +200°C
- LubricationSelf-lube / Grease
Part Number & Size Table
POS / PHS / SA / SI | 304 / 316 / 420 / 440C
Step 1: Select Structure (Male/Female)
Step 2: Filter by Series & Material
| Part No. | Series | Thread | Bore (d) | L (mm) | H/W (mm) | C1 (mm) | Material | Notes |
|---|---|---|---|---|---|---|---|---|
| POS 6 | POS | M6x1 | 6 | 46 | 20 | 9 | 304 | RH |
| SA 6 E | SA | M6x1 | 6 | 36 | 18 | 8 | 440C | PTFE |
| POS 8 | POS | M8x1.25 | 8 | 54 | 24 | 12 | 304 | RH |
| SA 8 E | SA | M8x1.25 | 8 | 42 | 22 | 10 | 440C | PTFE |
| POS 10L | POS | M10x1.5 | 10 | 62 | 28 | 14 | 304 | LH |
| POS 10 | POS | M10x1.5 | 10 | 62 | 28 | 14 | 316 | RH |
| POS 12 | POS | M12x1.75 | 12 | 70 | 32 | 16 | 316 | RH |
Recommended Accessories
High Misalignment Spacers
Increase misalignment angle capability and eliminate binding. Perfect fit for our rod ends.
Jam Nuts & Lock Nuts
Essential for securing rod end position. Available in standard and fine threads (RH/LH).
Clevises & Yokes
Complete your linkage system with matching stainless steel clevises and yoke ends.
Industry Applications
Food Processing
Frequent washdowns and high sanitation requirements.
Marine & Offshore
Extreme salt spray and corrosive ocean environments.
Packaging Machinery
High cycle rates and continuous 24/7 operation.
Motorsport Linkages
High load, high vibration, and critical safety needs.
Quality Assurance & Compliance
We provide stable supply and consistency control for all stainless steel rod ends. Full material traceability and inspection documentation are standard operating procedures.
Documentation
Material Certs, Dimensional Reports, RoHS/REACH compliance.
Testing & Inspection
100% Dimensional check on critical fits. Batch testing for load capacity.
Factory Capacity
Advanced CNC turning centers ensuring high precision and output.
Frequently Asked Questions
The main differences lie in structure (Male/Female) and series (Standard/Heavy Duty/Compact). POS/SA are generally Male thread, while PHS/SI are Female. Tell us your installation space, load, and environment, and we can recommend the exact series.
Yes, we support both Male and Female thread configurations. Left-Hand (LH) threads are available as an option across most series (typically marked with an 'L' suffix).
For general wet environments, 304 is sufficient and cost-effective. For salt spray, marine environments, or frequent chemical washdowns, 316 is the priority choice.
420 and 440C are heat-treatable stainless steels offering much higher hardness and wear resistance. They are ideal for high-wear/high-strength mechanical connections but have lower corrosion resistance compared to 316.
We offer both maintenance-free types (with PTFE liners) and re-lubricatable types (with grease fittings). Selection depends on your series preference and operational conditions.
Yes, we can provide standard 2D dimension drawings or 3D STEP files for your specific model upon request.
MOQ depends on the series and size. Standard items may have lower MOQ. Lead times are quoted upon inquiry but we generally offer competitive turnaround.
Absolutely. Please provide your drawing, sample, or key dimensions along with usage environment details, and we can quote a custom solution.
Request a Quote
Stainless Steel Rod Ends (POS / PHS / SA / SI)
Get a faster quote
Helping us understand your exact needs reduces back-and-forth emails.
Essential Info
- Series (POS/PHS...)
- Thread Size (e.g. M10x1.5)
- Quantity (Impacts price tier)
Helpful Context
- Application Environment
- Load Requirements
"Unknown model? Just upload a photo of your current part next to a ruler, and tell us the thread size."
